Hydrothermal Synthesis Autoclave Reactor with PTFE Lined Vessel Teflon Chamber

$29.00

Specification

HSAR-25
HSAR-50
HSAR-100
HSAR-200

Hydrothermal Synthesis Autoclave Reactor

Max working pressure: 3mpa (gauge); Max temperature: 220℃
Made of standard stainless steel 304 with high quality PTFE chamber
Hydrothermal reactor can quickly and completely dissolve the sample containing volatile elements and the sample
Autoclave reactor features good corrosion resistance, anti-fouling, leak-proof to prevent harmful substances spilling
This reactor widely applies in the petrochemical, biomedical, materials science, geochemistry, environmental science, food science, commodity inspection and other departments of the research and production

PTFE or PFA Sampling, Washing or Dosing Bottles are available.

Product description
3MPA Hydrothermal Synthesis Autoclave Reactor with PTFE Lined Vessel Teflon Chamber
The hydrothermal reactors, made of standard stainless steel 304, features high quality PTFE chamber, up to 220℃ and 3Mpa, is able to replace platinum crucible to solve sample treatment problem about the trace. With this reactor can shorten the analysis time, but get reliable data
Specifications
Volume: 25ml, 50ml, 100ml, 150ml, 200ml, 250ml, 300ml, 400ml, 500ml
Stainless size: Dia=121mm , height=220mm
PTFE chamber size: Dia=84mm, height=148mm, thickness=80mm
Seal Structure: sealed by PTFE chamber(between cover and body)
Shell Material: stainless steel 304
Chamber Material: High quality PTFE
Max temperature: 220℃
Max pressure: 3Mpa
Package dimensions: 14.17x7.48x6.3 inches
Shipping weight: 17.82 lbs
Package Included
1 x Hydrothermal Synthesis Autoclave Reactor
Hydrothermal Synthesis Autocalve Reactor
NOTE
When used, it is strictly prohibited from and overpressure use. Do not exceed the maximum temperature, working pressure up to 3MPa (gauge pressure)
The inner cup capacity is up to 80%. If the amount of the gas production by reactants is extremely large, it is recommended the cold nitration overnight, in particular, all with perchloric acid, hydrogen peroxide
