K12 Chuck Four Jaw Self-centering Chuck for CNC mill or Lathe

Four-jaw self-centering chuck K12 Lathe Chuck

Specifications:
Jaws material: Hardened Steel
Model: K12-80
Max RPM: 6600 r/min
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting.
2. Model K12 chucks are provided with one-piece jaws(which include a set of internal jaws and a set of external ones ).
3. Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 2- 22mm
Jamming Range B-B1: 25- 70mm
External Jaw
Clamping Range C-C1: 22- 63mm
Packaged included:
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3

Specifications:
Jaws material: Hardened Steel
Model: K12-100
Max RPM: 3500 r/min
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting.
2. Model K12 chucks are provided with one-piece jaws(which include a set of internal jaws and a set of external ones ).
3. Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 2- 30mm
Jamming Range B-B1: 30- 90mm
External Jaw
Clamping Range C-C1: 30- 80mm
Packaged included:
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3


Specifications:
Jaws material: Hardened Steel
Model: K12-125
Max RPM: 3000 r/min
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting.
2. Model K12 chucks are provided with one-piece jaws(which include a set of internal jaws and a set of external ones ).
3. Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 2.5- 40mm
Jamming Range B-B1: 38- 125mm
External Jaw
Clamping Range C-C1: 38- 110mm
Packaged included:
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3


Specifications:
Jaws material: Hardened Steel
Model: K12-130
Max RPM: 3000 r/min
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting.
2. Model K12 chucks are provided with one-piece jaws(which include a set of internal jaws and a set of external ones)
3. Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 3- 40mm
Jamming Range B-B1: 40- 130mm
External Jaw
Clamping Range C-C1: 40- 120mm
Packaged included:
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3




Specifications:
Jaws material: Hardened Steel
Model: K12-160
Max RPM: 2500 r/min
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting.
2. Model K12 chucks are provided with one-piece jaws(which include a set of internal jaws and a set of external ones ).
3. Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 3- 55mm
Jamming Range B-B1: 50- 160mm
External Jaw
Clamping Range C-C1: 55- 145mm
Packaged included:
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3





Model: K12-200
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting.
2. Model K12 chucks are provided with one-piece jaws(which include a set of internal jaws and a set of external ones)
3. Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 4- 85mm
Jamming Range B-B1: 65- 200mm
External Jaw
Clamping Range C-C1: 65- 200mm
Packaged included:
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3
